Form Factor
10U Rackmount
W x H x D: 448x 441 x 850 mm
(17.63x17 36 x 33.46 inch)
Processor
5th Gen AMD EPYC™Processors up to 400W
PCIe Slot (from MLB)
Option(1) 1x FHHLDW
Option(2) 2x FHHLSW
Option(3) 1x OCP 3.0 SFF + 1 x FHHLSW
PCIe Slot (from Switch)
8x Low Profile card (PCIeG5x16)
Storage (from Switch)
8x U.2 NVMe SSD bays
Storage (from MLB)
4x U.2 NVMe SSD bays from CPU (option)
2x M.2 NVMe SSD
System Management
1x RJ45 for BMC(AST2600) remote management
Power Supply
3300W 54V ATS PSU, support 4+2 redundancy
2400W 12V PSU, support 1+1 redundancy
Support S5 power and thermal for DPU
Fan
15x 8086 Fan for GPU cooling
5x 8056 Fan for CPU cooling
