EdgePro 1U

Next-Gen Modular Edge Solutions
  • Compact 1U Modular Edge Server Based on Intel Xeon 6 Platform
  • Ultra-Short Depth (438mm) Design for Space-Constrained Deployments
  • Block-based modular design enables independent upgrades of GPU, storage, and networking — extending lifespan and lowering replacement cost
  • Optimized for low-latency edge AI and data preprocessing — ideal for smart surveillance, roadside traffic nodes, factory AOI, smart retail, and medical image triage.
  • Built-in Security Features: TPM 2.0, Secure Boot, and Firmware Protection for Trusted Edge Computing

The Inventec EdgePro series servers unleash edge computing potential. Featuring a compact, short-depth chassis ideal for limited spaces. The modular architecture ensures adaptability and supports future upgrades. These servers provide exceptional computing power for AI, Networking, and more. Powered by the latest Intel Xeon 6 CPUs, high-speed DDR5-6400, and PCIe Gen5 GPUs for demanding edge deployments where space is critical.


Single-Socket Intel Xeon 6 Platform
Supports Socket-E2 with up to 270W TDP, DDR5-6400 memory, and PCIe Gen5 expansion, enabling efficient edge computing with balanced power consumption.

Dual PCIe Gen5 Slot Design
Equipped with two PCIe Gen5 x16 slots supporting HHHL or FHHL single-slot GPUs, NICs, or accelerators such as NVIDIA L4.

Flexible High-Density Storage Options
Supports up to 4x M.2 Gen5 and 6x E1.S Gen5 SSDs, allowing up to 46TB of total storage with optional hardware/software RAID 0/1/5.

Comprehensive Management and Security Functions
Features Redfish API, IPMI 2.0, HTML5 KVM, TPM 2.0, and Secure Boot to support secure and centralized edge node management.

Item
Description
Form Factor
1U1N1P W x H x D: 438x42.88x438.6mm
(17.24” x 1.69” x 17.27”)
Processor
Single Socket-E2 (FCLGA4710)
Intel® Xeon® 6, 6500/6700 Series, up to 270W.
Memory
8 x DDR5-6400 R-DIMM, 1DPC, up to 1TB capacity.
Storage Controller
4 x NVMe Gen5x4 M.2, 2280 or 22110, up to 15.36TB capacity
6 x NVMe Gen5x4 E1.S, up to 46.08TB capacity. (Optional)
Support Intel VROC
Network Controller
Embedded Intel i210 1Gb 2 ports
Expansion Slot
2x PCIe Gen5x16 Low Profile slots
2x PCIe Gen5x16 SS FHHL slot
System Management
DC-SCM 2.2 Module with:
1 x USB3.0 port
1 x Mini Display port
1 x RJ45 management port
Power Supply
AC-DC CRPS 800W/1500W, Support 1+1 Redundant
Fan
4 Dual Rotor Fans
Support N+1 Redundant with Optimal fan speed control
High PQ Performance & Low Power Consumption
