EdgePro 2U

Next-Gen Modular Edge Solutions
  • Supports two double-width GPUs to accelerate edge inference and analytics
  • Block-based modular design enables independent upgrades of GPU, storage, and networking — extending lifespan and lowering replacement cost
  • Ultra-Short Depth (438mm) Design for Space-Constrained Deployments.
  • Optimized for near-edge environments with a balance of high performance and flexible deployment
  • Equipped with 1+1 redundant PSU and hot-swappable fans for better serviceability and uptime

The Inventec EdgePro series servers unleash edge computing potential. Featuring a compact, short-depth chassis ideal for limited spaces. The modular architecture ensures adaptability and supports future upgrades. These servers provide exceptional computing power for AI, Networking, and more. Powered by the latest Intel Xeon 6 CPUs, high-speed DDR5-6400, and PCIe Gen5 GPUs for demanding edge deployments where space is critical.


Powered by High-Performance Intel® Xeon® 6 CPU and DDR5 Memory
Supports single-socket Intel® Xeon® 6500/6700-series processor with E-cores or P-cores with up to 350W TDP and 8x DDR5-6400 DIMM slots, allowing up to 2TB memory for demanding inference and data aggregation workloads.

High-Power Dual-GPU Support
Supports up to two double-width PCIe Gen5 GPUs, each up to 350W (e.g., L40S), with a total system power budget of 1500W for demanding AI workloads.

OCP Edge MHS Modular Architecture
Modular design with OCP Edge MHS support including HPM, storage, NIC, and management modules for easy customization, upgrade, and interoperability.

Flexible I/ and Storage Configurations
Supports up to four PCIe slots (2x double-width or 4x single-width), allowing mixed configuration with FHFL/FHHL cards, M.2 NVMe, and HDD modules.

Item
Description
Form Factor
2U1N1P W x H x D: 438 x 87.6 x 438.6 mm
(17.13” x 3.45” x 16.93”)
Processor
Single Socket-E2 (FCLGA4710)
Intel® Xeon® 6500/6700-series processor with E-cores or P-cores, up to 350W, 144 cores
Memory
8 x DDR5-6400 R-DIMM, 1DPC, up to 2TB capacity.
Storage Controller
4 x NVMe Gen5x4 M.2, 2280 or 22110, up to 15.36TB capacity.
6 x NVMe Gen5x4 E1.S, up to 46.08TB capacity. (Optional)
Support Intel VROC
Network Controller
Embedded Intel i210 1Gb 2 ports
Expansion Slot
2 x PCIe Gen5 Low Profile slots
4 x PCIe Gen5 FHFL slot
2 x PCIe Gen5 FHHL slot or 2 x Double Slot
System Management
DC-SCM 2.2 Module with:
1 x USB3.0 port
1 x Mini Display port
1 x RJ45 management port
Power Supply
AC-DC CRPS 800W 1500W, Support 1+1 Redundant
Fan
6 Dual Rotor Fans
Support N+1 Redundant with Optimal fan speed control
High PQ Performance & Low Power Consumption
