K709G6

2U1N NVIDIA® Grace™ CPU Superchip
  • Comply with NVIDIA® MGX™ architecture
  • Supports up to 4x Dual slot Gen5 GPUs
  • High-performance for HPC and cloud computing
  • Better performance with lower power consumption
  • 900GB/s NVIDIA® NVLink®-C2C Interconnect
  • Up to 960GB CPU LPDDR5X ECC memory
  • Support OCP 3.0 SFF
  • Efficient management system controlled and monitored remotely
Item
Description
Form Factor
2U1N
900mm x 438mm x 87.0mm NVIDIA® MGX compliance
(33.4 x17.2 x3.42 inch)
Processor
Support NVIDIA® Grace™ CPU Superchip Up to 144 cores @3.2GHz, TDP to 600W
Memory
LPDDR5X, 480G module supports 4266MT/s；960G module supports 3200MT/s
Storage/PCIe
Up to 12x NVMe SSD, U.2 form factor,Support 2x NVMe SSD for each BP ​
GPU
Up to ⁠4 FHFLDW PCIe GPU Card
Network Controller
Supports SFF OCP 3.0 card x1
Server Management
ASPEED AST2600
BMC NCSI connect to OCP 3.0 slot
10M/100M/1G Ethernet MAC controller
TPM
TPM 2.0
Power Supply
CRPS power supply support 100V-240V,
240V HVDC support 1+1 active-active support hot plug
Fan
3+1 8056 Fan (dual motors) , Support Hot-plug​​​
