Positioning
High Density Computing
Form Factor
2U4N8P
W x H x D: 448x 875x 916 mm
(17.63x 3.44x 38.43 inch)
Processor
Intel Socket (LGA4677)Sapphire Rapids + HBM (optional) (2 Processors)
Emerald Rapids (2 Processors)
Memory
8 channels DDR5 per CPU @ 4800MTS/5600MTS (1DPC)
(Total : 16 DIMMs)
PCIe Lanes
PCIe Gen5 80 lanes
Chipset
PCH: Intel Emmitsburg
BMC: Aspeed AST2600
Storage Controller
Support up to 2 x U.2 NVMe SSDs per node
Support 1x M.2 22110
Network Controller
Intel I210 1Gb single port (Support Share NIC)
x16 OCP 3.0 Slot (Support Share NIC)
Expansion Slot
1 x PCI-E Gen5 x16 slot (R1)
1 x PCI-E Gen5 x16 slot (R2)
System I/O
Rear(per node)
• 1x USB 3.0 ports
• VGA output port
• 1x Power button with LED
• 1x UID button with LED
• 1x RJ45 management port
• 1x RJ45 1G port
• 1x health LED
VGA
Video integrated into BMC
Thermal Sensor
TMP468
TMP75
Power Supply
4x 2400W PSUs (Titanium), Support N+1 Redundant
Fan
4x 4056 Fans per node
