B880G4 motherboard targets general purpose usage for enterprises and datacenters with dual Intel® Xeon® Scalable Processors, sixteen DIMM capacity (up to 2TB with 128GB DIMMs) and rich expansion choices from OCP2.0 and PCH PHY mezzanine, as well as standard PCIe Gen3 slots. Offering better flexibility and higher performance in standard EATX form factor, B880G4 is made widely applicable for a great variety of virtualization solutions, big data analysis scenarios, among others. The series presents,
Advanced Computing Performance: B880G4 is based on dual Intel® Xeon® Scalable Processors with optional support of single CPU operation, enabling latest Intel® technologies such as such as Intel® Optane™Persistent Memory which is ready with 2nd Gen Intel® Xeon® Processor Scalable Family, and boosted performance, including 1.5x memory bandwidth, 2x FLOPs capability, and faster socket interconnection compared with previous platform.
High Scalability and IO Flexibility:B880G4 boasts high-level of IO flexibility that optimizes the scale-out fabrics, offering multiple storage options, which include two M.2 SATA SSDs from SATA connectors, or two M.2 NVMe via interposer connections, and a variety of storage mezzanine cards. Meanwhile, a variety of network choices are provided through the PCH PHY and up to two OCP 2.0 mezzanine slots, ranging from 10G Ethernet to 100G (optical or Base-T, compatible with OCP 2.0). Standard PCIe card option is supported too by the PCIe Gen3 x16 expansion slot. The high-speed performance and IO flexibility are realized by B880G4, catering to suitable demands of diﬀerent application procedures.
Dual Socket (LGA-3647); Intel® Xeon® Processor Scalable Family
TDP: up to 205W
Onboard: 2x SATA connector,
3x miniSAS HD connector;
Up to 14x SATA3 6Gb/s port
Intel RST RAID 0/1/5/10
Supporting optional 2x M.2 SATA, or 2x M.2 NVMe via interposer connector
Supporting Inventec Storage HBA/RAID Card
